- It adopts Schneider AC contactor, high-power Solid-state booster and intelligent temperature controller to make temperature system more accurate, prolong the working life.
- It adopts solid roller conveyor, the rollers wrapped with high temperature silica gel tube. It can stand heavy product and difficult abraded (you can choose net type conveyor)
- It adopts high-power fan motor to ensure enough strong wind to reach perfect packing effect.
- Inside wall adopts stainless steel, it has fast temperature transfer, even heating, low energy consumption, long working life characteristics.
application：
This machine is widely used in foodstuff, drinks, printing, pharmaceutical, floor, hardware and other industries shrink packaging. It is suit POF, PE, PVC and other packaging material
|
|
Model |
QL5545 |
BS-D4520 |
| Max packing size、 |
L450×W350×H100 |
W450×H200 |
| Max width of film |
500mm |
|
| Min packing size (mm) |
L:60mm |
|
| Max sealing size （㎜） |
L550×W450 |
/ |
| Power KW |
1.30 |
8.5 |
| Capacity （㎜） |
0-25 pcs/min |
0-15 m/min |
| Voltage |
220V 50/60HZ |
380V 50HZ/60HZ |
| Sealing temperature （ ） |
180 —250 depends on thickness of film and environment temperature |
/ |
| Thickness of film(mm) |
0.015 0.10 |
/ |
| Air pressure(Kg/cm2) ) |
5 |
/ |
| Packing material |
PE POF PVC |
/ |
| Machine weight( ) |
320 － |
210 |
| Machine size |
L1700×W900×H1400 |
External L1600×W900×H1400 tunnel L1200XW450XH200 |
